30X340 mesh twill dutch mesh

Hot Products
Related Knowledge
Introduction

Mesh:  30X340mesh
Wire Dia:  0.28X0.16mm
Aperture:  89μm
Material:  201,202,301,302,304,304L,316,316L,321,430
Weave Type:  twill dutch
Roll Width:  1.0m,1.2m,1.5m
Roll Length:  30m
Application:  Separating,Filtering,Diffusing

Add Inquiry
Description

30X340 mesh twill dutch weave stainless steel wire mesh


Standard

u JB/T 5979-92

u Anping Web Wire Mesh Co.,LTD Twill Dutch Weave Process and Technical Parameter


Brief description

30X340 mesh twill dutch weave stainless steel wire mesh.Using 0.28X0.16mm diameter wire, by twill dutch weaving, woven 30X340 mesh opening for 89μm solid particles , it can also be used as a liquid, gas coarse filter support material or protective fabrics to use.This wire diameter and mesh with ratio reasonable, therefore weave structure is very strong. After 13 whole weaving process, so that the mesh surface flatness better.


Material

u 200 series: 201 202 205

u 300 series: 301 302 304 304L 309 309S 310 310S 316 316L 321

u 400 series: 410 420 430


Technical parameter



roll width: 1.0-1.6m

roll length: 30m


Application

u Separating

u Filtering

u Diffusing


30X340 mesh twill dutch weave stainless steel wire mesh packing

Stainless steel wire mesh is packed in rolls,winding on a paper tube,wrapped in moisture-proof paper

or plastic film, outside wooden cases or wooden pallet.
